SX-E Turbo S364 64.47mm 8776 13009097008

Borg Warner SX-E Turbo S364 – 64.5mm 8776

Utilizing the latest generation 64.47mm billet EFR compressor wheel aerodynamics with uprated 360 degree thrust assemblies, the all new ‘SX-Enhanced’ turbos redefine performance and value for modern turbochargers.

This proven design is packaged in a purpose built SX-E compressor housing with ported-shroud inlet and speed sensor port. It is paired with traditional Airwerks 76mm Inconel Turbine and Flexible Housing options.  The 64.47mm S300SX-E Turbo has smaller overall dimensions than the EFR8374 and higher airflow rates, which make this an excellent match for high-boost and high-power 64.5mm drag racing applications.  Thermals are taken care of by an Oil-Cooled Journal Bearing only.

Key Features:

• 360 degree thrust bearing
• Compressor cover integrated speed sensor port and pre-machined boost port
• Flexible compressor cover outlet options (S300SX-E only)
• Forged milled (billet) compressor wheels with extended tip technology
• Optimized compressor stage aerodynamics
• Interchangeable with existing turbine housings for upgradability

The BorgWarner super core assembly consists of the compressor cover attached to the cartridge, all cartridge to turbine housing mounting hardware, clamp plates, cap screws and mounting gaskets. Speed sensor and turbine outlet V-band are not included with turbo assemblies.  Choose a turbine housing from our extensive list of factory housings as well as our custom cast performance housings.

Compressor Specifications

• Compressor Type: Forged-Milled Wheel (FMW) Extended Tip
• Compressor Wheel OD (Exducer): 87.37mm
• Compressor Wheel Inducer: 64.47mm
• Max Flow Rate: 85 lb/min
• Max Recommended Turbo Shaft Speed: 122374 RPM (560 m/s)
• Compressor Housing Connections:
  • Inlet: 4.0″ Hose Coupler
  • Outlet: 2.5″ Hose Couple

Turbine Specifications

• Turbine Type: Inconel S300SX Turbine Wheel
• Turbine Wheel OD: 76mm
• Housing Material: D5S sandcast
• Housing Size and A/R ratio: S300SX-E 8776 (S364) is available in three (3) different turbine housing configurations:
  • 0.88 A/R T4 Single Scroll
  • 0.91 A/R T4 Twin Scroll
  • 1.00 A/R T4 Twin Scroll
• Turbine Outlet: 3″ Marmon OR Optional 3″ V-Band
